Non-expandable HD OBVAN based on Blackmagic ATEM vision mixer. This OB can do a production of 5 cameras SONY HDC1500, 2 x wireless system with control, 1 x EVS replay system, Graphics, and tapeless recorders “Hyperdeck Studio Pro”.

This OB is equipped with YAMAHA O1V96 Console and ClearCom intercom System.

Unit 3
Unit 3
Unit 3
video equipment
CAMERA SYSTEM
HDC 1500 (5)
WIRELESS CAMERA SYSTEM
Vislink L1500 (2)
CAMERA CONNECTION
Fiber Optic LEMO SMPTE
CAMERA LENSES
Canon
TRIPODS
CARTONI
VINTEN
SACHTLER
CAM-GEAR
HD VISION MIXER
Blackmagic ATEM 1 M/E
CHARACTER GENERATOR
Title Box
PRODUCTION ROOM MONITORS
Samsung LCD screen (2)
SHADING ROOM MONITORS
JVC DT-V1710CG 17inch (2)
MULTIVIEWER SYSTEM
For A
HD VTRS
Sony HDCAM (1)
Digital Betacam (1)
TAPELESS RECORDERS
HyperDeck Studio Pro (5)
GLUE
Blackmagic
WAVEFORM
Blackmagic
Audio Equipment
AUDIO MIXING CONSOLE
Yamaha O1V96i
AUDIO MATRIX
Yamaha OV1 (16 input — 8 output)
MICROPHONES
Sennheiser
MULTITRACK RECORDING
AVAILABLE IF REQUESTED ANALOG OR DIGITAL
AUDIO EFFECTS
Yamaha SPX 990 - TC 6000
AUDIO MEASUREMENT
Decibel
Vumeter
Intercom Equipment
INTERCOM SYSTEM
Clear-Com Matrix Plus II
WIRELESS TALK-BACK INTERCOM SYSTEM
Clear-Com HME
Riedel Riface with MOTOROLA Base Station and Motorola Radios
Kenwood Base Station with Motorola Radios
HYBRID SYSTEM
Glensound GSM Hybrid
Glensound Analog Landline Hybrid
Glensound Digital ISDN Hybrid
Coach Build
Length
5 meters
Width stowed
2 meters
Width expanded
None
Height
3 meters
Weight
4 t
System Integrator of HD/UHD OBvan
7 Production
Coach Builder of HD/UHD OBvan
United Kingdom
INTERIOR
MONITOR WALL LAYOUT
